engineering_drawing_1 — engineering_drawing

7 pages, 3 questions

engineering_drawing_1_q1: In which direction can you see the eight temperature sensing manifold?
SourceAnswerMatch
TargetD
geminiD✓
lunaD✓
engineering_drawing_1_q2: How many clamps are used in total?
SourceAnswerMatch
Target27
geminiUnknown✗
luna27✓
engineering_drawing_1_q3: Which labeled parts are used at the end of the tube with identifying number 1901105? List the part identification numbers, separated by commas, in the order they are placed after the tube.
SourceAnswerMatch
Target1901069-002, 1901094, AN 910-2, 1016315-001
gemini* **Step 1:** Locate the part with the identifying number "1901105" in the Bill of Materials (BOM) on Sheet 1. * **Step 2:** In the BOM table, find the row where the "PART OR IDENTIFYING NO." is "1901105". This corresponds to "FIND NO." 113. The description is "TUBE ASSY, FLEX, METAL". * **Step 3:** Locate the part labeled with the Find Number "113" in the assembly drawings. Sheet 7 provides the clearest view of the tubing assemblies. * **Step 4:** Examine the connections at the end of the tube labeled "113". The drawings show that the tube (113) is connected to another component via two intermediate parts. * **Step 5:** Following the tube (113) to its connection point, the first part it connects to is labeled with Find Number "124". * **Step 6:** The part labeled "124" is then followed by the part labeled with Find Number "123", which connects to the main assembly block. * **Step 7:** The question asks for the part identification numbers in the order they are placed after the tube. Therefore, the order is 124, then 123. * **Step 8:** Format the answer as a list separated by a comma and a single space, as per the mandatory rules. FINAL ANSWER: 124, 123✗
luna144, 141✗
